Viega Pexfit Pro – the flexible system for all potable-water and heating installations

Viega SC-Contur

All Pexfit Pro connectors feature the tried and tested Viega SC-Contur, which makes inadvertently unpressed connections immediately visible.
No sealing element

The Pexfit Pro connectors in the dimensions 16 to 25 mm do not require a sealing element, which means one less component that can be damaged, contaminated or slip out of place.
Quick assembly

Cut the pipe to length, attach the connector, press – after just three steps, the connection is complete and ready for a full load. No need for time-consuming calibration.
PPSU

The 16- to 25-mm Pexfit Pro connectors are made of a high-performance PPSU plastic.
Gunmetal

The 32- to 63-mm Pexfit Pro connectors are made of robust gunmetal.

High cost efficiency meets reassuring safety

The Viega Pexfit Pro system combines a whole range of compelling advantages for all potable-water and heating installations. The dimensionally stable press connectors are made of highly resistant PPSU and robust gunmetal and meet high standards of safety and hygiene. Thanks to the innovative press connection technology, you also benefit from very simple and economical installation.

3 reasons for potable-water and heating installations with Pexfit Pro
A particularly high safety standard thanks to high-quality material and the proven Viega SC-Contur
Fast and economical installation in just three steps thanks to efficient Viega press connection technology
High flexibility thanks to an extensive range of dimensions from 16 to 63 mm
Close

Areas of application

Special features of the Pexfit Pro system

Uncompromising safety

Thanks to extremely robust materials and innovative Viega press connection technology, the Pexfit Pro system ensures reliable connections. All connectors are also equipped with the tried and tested SC-Contur, which immediately reveals any inadvertently unpressed connections during the leakage test.

Multi-layer pipe

Viega Pexfit Pro pipes of the dimensions 16 to 63 mm are made of polyethylene with an aluminium layer as an oxygen barrier layer in accordance with DIN 4726. They are particularly dimensionally stable and at the same time easy to bend even in small radii – an advantage especially in installations in confined spaces.

Robust gunmetal

The Pexfit Pro press connectors of the dimensions 32 to 63 mm are made of gunmetal , a high-quality material that combines excellent corrosion resistance with outstanding hygiene properties.

Significant time and cost savings

With the Pexfit Pro system, you can significantly reduce your labour and costs. Simple installation with the Viega Pexfit Pro hand press tool or the Viega Pressgun requires no expansion or calibration.

High flexibility

The possibilities with Pexfit Pro are as varied as the customer’s wishes and local conditions. To meet all requirements, Viega offers Pexfit Pro, a comprehensive system with a versatile range of connectors consisting of elbows, T-pieces, manifolds and couplings in dimensions from 16 to 63 mm.

Assembly with Pexfit Pro - quick, clean and safe

Step 1

Cut the pipe

Cut the pipe to length using pipe shears. After that, no further calibration is required.

Step 2

Fit the press connector

Attach the press connector to the pipe and apply the press jaw. No expansion or calibration is necessary, as all components are pre-assembled. No additional tools are required. A window allows the insertion depth to be checked before and after pressing.

Step 3

Press

Force-fit the press connector and the pipe using a Viega Pexfit Pro hand press tool or a Viega Pressgun . Here too, the SC-Contur offers maximum safety.

And that’s it!

The result is a tight and secure connection that is immediately ready to bear the full load.

1 / 4

Click here for the instructions for use

The Viega Pexfit Pro product range

Pexfit Pro puts you on the safe side for all potable-water and heating installations. The product range of pipes, elbows, T-pieces, manifolds and couplings in dimensions from 16 to 63 mm provides the perfect economical solution for any challenge. Discover the comprehensive Pexfit Pro product range from Viega.
